AVR Trainer Learning Board

UwU very satisfying board, the color, precision route, i love it!. i'm using china post and arrive in 21 days. Few week ago i have a dream, i want to make controller board that suitable for beginner. easy for learning and portable on size. Then i try to design it. but i have no idea where i'll to make it real. after some research, i found this site, first order i try to asking some question, and they are very fast respond. On my trainer board, i put lcd 16x2, step down for supply, UART communication, RTC, seven segment, on board keypad, DHT11, LM35, trimpot (for ADC reading), and photo diode. And i have new idea. I want to make new learning board for Internet Of Things. and i'll put it on pcbway soon as i can. great work! good services!






Aug 08,2019
