Description
Tad Boy Color
The Tad Boy Color is a fully custom, miniaturized Game Boy Color asking a simple question: just how small can you make a GBC while still using the original cartridges?
Using the original CPU and RAM from a Game Boy Color, nearly everything else here is built from the ground up:
- Shell that can be machined in a variety of materials
- 4-layer PCB
- Custom glass lens
- 3D printed cartridge shield, light pipe, etc
The BOM and production files for complete project assembly are available at the project's GitHub repo.
CAD-Custom parts and enclosures
Front Shell 083124
tbcFront083124.step
tbcFrontTD083124.pdf
Back Shell 083124
tbcBack083124.step
tbcBackTD083124.pdf
Volume Wheel 083124
ftbcVolumeWheel083124.step
ftbcVolumeWheelTD083124.pdf
Cartridge Shield 090124
cartShield090124.step
Light Pipe 081224
lightPipe_081224.stl
GitHub Project
https://github.com/leggomyfroggo/TBC
Sep 28,2024
18,608 views
end-flag
Tad Boy Color
4 Layers PCB 85 x 56.4 mm FR-4, 1 mm, 1, HASL with lead, Green Solder Mask, White silkscreen
The Tad Boy Color is a fully custom tiny Game Boy Color based on the original chips.
18608
52
5
10.00 (2)
Published: Sep 28,2024
BOM(Bill of materials)
Centroid file
PCBWay Donate 10% cost To Author
File Last Updated: 2024/10/06 (GMT+8)
File update record
2024-10-0610:58:25
Centroid file is updated.
2024-10-0103:39:09
CAD or technical drawing file is updated.
Only PCB
PCB+Assembly
*PCBWay community is a sharing platform. We are not responsible for any design issues and parameter issues (board thickness, surface finish, etc.) you choose.
Under the
Attribution-NonCommercial-NoDerivs (CC BY-NC-ND)
License.
