Mezzanine Maestro

This was a simple project for a Mezzanine PCB for an Arduino Mega. The Mezzanine interfaces the control of a step motor driver and some external switches. The order of my project in the PCBWay platform was straightforward and intuitive. Also, the process of evaluating, confirming, and performing the project's PCB was very fast. The shipment was on time, and the quality of the PCB is fantastic. I highly recommend the service as I was delighted with the results.



Sep 24,2024
489 viewsReport item
