Stencil for Atmega328P card

Stencil for assembly :) I really should not have ordered this, as there are only 2 SMD components on the entire board, but I did not pay attention at checkout, and ordered a stencil as well. No harm in that, as the stencil is high quality, and I will use it anyway..



Aug 22,2022
