SNES Controller Tac Switch Mod
This is a replacement PCB for the SNES/SFC controller specifically for the placement of SKRRAAE010 tac switches to give the controller buttons a clicky feeling. An OEM SNES/SFC controller is required to harvest the cable board connector(J1), but all other parts can be bought new/NOS.
This is the main PCB only. Trigger boards can be carried over from the harvested SNES controller, or replaced with the following tac switch replacement(by CMR779): https://oshpark.com/shared_projects/ztkl5JxY
