    Product Description

    Smart Soldering Iron TS100

    Features:

    • Control part: TS100’s shell is made of polycarbonate plastic, while employs 304 stainless steel embedment for inserting soldering tips. It is designed with safety circuit and anti-static structure, integrated with DC5525 12-24V port, dual-temperature sensors and accelerated sensors with STM32 chip. Under these features, the temperature can be controlled accurately, stably and easily adjusted from 100°C to 400°C, and the TS100 also has sleep mode and automatic over-heating warning.
    • Soldering tip heating end: built-in heating core, pocket-size making it more convenient. Seven replaceable tips meet your different needs.
    • External power supply: DC5525 power port is compatible with DC 12-24V laptop AC adapter/power bank/car power.
    • Micro USB port interface: set up config files to design your own temperature rising curves and custom functions.
    • Additional function: open-source application layer.

    Specifications:

    • Power: 65W
    • Temperature stability: ±2%
    • Soldering tip resistance to ground: <2Ω
    • Temperature range: 100℃ - 400℃ (max)
    • Max operation ambient temperature: 40°C
    • OLED screen
    • Micro USB port
    • DC5525 port
    • 7 types of soldering iron tips available
    • Fashionable and detachable
    • Open source
    • Efficient to work with
    • Wide compatibility
    • Control part: length: 96mm, diameter: 16.5mm
    • Heating part: length: 72+33mm, diameter: 5.5mm
    • Weight: 33g (power adaptor not included)
    • Compliant with EU certification: CE FCC
