I ordered the solder paste stencil for some boards with 0603-sized smd components and other very small IC packages. The stencil with the frame allows easier drafting and enables the soldering of small...
We use this stencil to apply solder paste to the GBA before mounting the SiPM chip.
First time for me. Excellent result soldered with electronic hot plate and hot air gun.
This is my first time ordering SMD stencils and using them. It looks good and right size. Protectively packaged. Size is 104x81 mm. Thickness is 0.13 mm
While not really needed for this simple design, applying just the right amount of solder paste to the pads speeds up things with a precision module, like the SEEED Xiao. The stencil is accurate a...
An SMD stencil to make assembly a bit easier and faster. Well manufactures, accurate and great quality. Thank you
This Stencil has top and bottom sides of the board. It will be used to place solder paste on both sides of ESP32 LED Watch board. The thickness is standard 0.12mm with small apertures that fit 0402 si...
A SMD assembly stencil to make my life a bit easier with assembly. The stencil is accurate and well manufactured. Thank you
This is a prototype of a brain computer interface. The good experience I had at PCBWAY made my life really easier and help me to make a really quick prototype.
Good stencil quality.
The project was to create a control board for a pet feeder that would dispense a predetermined amount of kibble for our four-legged friends. I had the control board manufactured and it turned out to b...
A stencil to make life a bit easier and speed up assembly. Well made and thus well worth the additional cost. Thank you
A stencil to make my life a bit easier, Well manufactured and accurate, Thank you
Solder paste stencil ordered. The quality is excellent. The price of $10 for a stencil with 3500 holes is a fairy tale!
Stencil for assembly :) I really should not have ordered this, as there are only 2 SMD components on the entire board, but I did not pay attention at checkout, and ordered a stencil as well. No harm i...
All footprints are correct, and the stencil is of high quality, Thank you PCBWay
