Fusebit Doctor, AVR, Восстановление фьюзов микроконтроллеров

2 Layers PCB 75 x 100 mm FR-4, 1.6 mm, 1, HASL with lead, Green Solder Mask, White silkscreen
Fusebit Doctor AVR is a device for repairing AVR MCU fuses. Firmware on Fusebit Doctor AVR MCU. Восстановление фьюзов AVR микроконтроллеров
14712
18
13
6.68 (15)
Published: Apr 22,2019
Add to cart

*PCBWay community is a sharing platform. We are not responsible for any design issues and parameter issues (board thickness, surface finish, etc.) you choose.

Copy this HTML into your page to embed a link to order this shared project
Copy
Copyright Info

Attribution-ShareAlike (CC BY-SA) License

Read More⇒
Under the Attribution-ShareAlike (CC BY-SA) License.
gift
Smart Soldering Iron TS101-BC2
BUY NOW
gift
Raspberry Pi 5 7 Inch Touch Screen IPS 1024x600 HD LCD HDMI-compatible Display for RPI 4B 3B+ OPI 5 AIDA64 PC Secondary Screen（Without Speaker）
BUY NOW
gift
ESP32-S3 4.3inch Capacitive Touch Display Development Board, 800×480, 5-point Touch, 32-bit LX7 Dual-core Processor
BUY NOW
gift
MHP50-B5 Mini Hot Plate Preheater
BUY NOW
gift
Smart Soldering Iron TS101-BC2
BUY NOW
gift
Raspberry Pi 5 7 Inch Touch Screen IPS 1024x600 HD LCD HDMI-compatible Display for RPI 4B 3B+ OPI 5 AIDA64 PC Secondary Screen（Without Speaker）
BUY NOW
Topic
DIY Electronics
Atmega AVR Fusebit Doctor
  • Comments(13)
  • Likes(18)
Upload photo
You can only upload 5 files in total. Each file cannot exceed 2MB. Supports JPG, JPEG, GIF, PNG, BMP
0 / 10000

  • Dear desinger this last pcb i need if posible gerber file or pcb project files my e- marekshome@inbox.lv I buy here pcb . very good quality

    Apr 29,20230 Comments
    Reply

  • Здравствуйте. Не могу понять смысл конденсатора C1 между коллектором VT1 (+5v) и шиной RDY. Да и на схеме его нет. Пока его не убрал с платы доктор не видел контроллеров. Видимо он должен идти не на RDY, а на GND.

    Jun 12,20196 Comments
    leoloel 2019-06-13 21:45:31Reply

    https://www.youtube.com/watch?v=GUg0lF5XIVg&t=193s на 4:00 минуте.

    Michael Demidov 2019-06-19 23:55:46Reply

    Спасибо. Посмотрел. В ролике говорится про 22 pF, а Вашей спецификации он указан как 100nF. В ближайшее время потыкаю осцилом по ногам сокетов. Действительно ли там постоянно присутствует 12в. Попробую поставить 22 pF и посмотрю будет-ли доктор лечить.

    Sergei 2021-02-23 14:48:58Reply

    Этот конденсатор не нужен

    Jason Markham 2021-02-28 05:46:48Reply

    Why is it that after i uploaded v 2.11 all chips are not detected FAIL bad led on

    Ahmed Ibrahim Ahmed 2022-01-08 05:03:35Reply

    Hi, does it work for V2.11 with C1 (100nF) or (22pF) or I remove C1 ?

    Michael Demidov 2022-01-27 19:43:40Reply

    Я не ставил этот конденсатор.

    Reply

  • +5В и +12В постоянно приходят на восстанавливаемый контроллер. Транзисторы исправны. На RDY высокий уровень всё время.

    May 09,20210 Comments
    Reply

  • Jason Markham, According to log text, your ‘doctor’ in the parallel high voltage mode (hvpp). For attiny85 you should chose the serial high voltage mode (hvsp). Please change the “hvpp/hvsp” work mode by the specific button (jumper) on the pcb.

    Mar 11,20210 Comments
    Reply

  • i am getting this error when i try with a tiny85 AVR Atmega fusebit doctor (HVPP+HVSP) version 2.11 http://diy.elektroda.eu/atmega-fusebit-doctor-hvpp Usage in commercial/profit purposes not allowed AUTOMATIC HVPP MODE Init programming... DONE Read signature... 00 01 02 - FAIL! Trying T2313 pinout..00 01 02 - FAIL! No chip in socket or chip does not responding Please try again... Thank You

    Feb 28,20210 Comments
    Reply

  • Hi, may I get the gerber file f this fusebit doctor? my email address is anthonysymak@gmail.com Thanks very much Anthony

    Dec 15,20200 Comments
    Reply

  • VT1,VT3 smd transistor BC857 SOT-23 VT2 smd transistor BC847 SOT-23 Транзисторы с каким коэффициентом усиления используются? (BC857 - BC857A,BC857B, BC857C; BC847 - BC847A,BC847B, BC847C)

    Nov 13,20200 Comments
