AD7746_Project
The AD7746 is a high resolution, two channel, high linearity and high accuracy Capacitance-to-Digital Converter. It is designed for single or differential floating sensors and it has a 2-wire, I²C®-compatible serial interface.
The fully featured Evaluation Board is computer software operated through a USB connection, that enables the user to perform detailed analysis of the Capacitance-to-Digital Converter's performance. The included technical note describes the operation and set up of the evaluation board.
AD7746_Project
