ADRmu 10V DC reference standard
Tentative specs
Output Voltage Stability (± μV/V):
24 hour: < 0.3
Output Voltage Noise (0.1 - 10 Hz)(±μV/V rms)
< 0.03
Output Voltage Tempco (±μV/K)
< 0.04
Short circuit current (mA)
10
Isolation (M? to AC,PE)
> 10 000 M?
< 1000 pF
Output Protection
Output can be shorted indefinitely. Output protected against ESD.
Temperature Range (°C)
15 - 35
Schematic and Layout
PCB project on GitHub
https://github.com/marcoreps/ADRmu
Feb 27,2022
2,502 views
ADRmu 10V DC reference standard
4 Layers PCB 160 x 100 mm FR-4, 1.6 mm, 1, Immersion gold, Green Solder Mask, White silkscreen
Low cost 10V DC reference standard in DIN 41612 modular enclosure. Based on ovenized LTZ1000 / LTZ1000A or ADR1000A zener diodes.
2502
2
0
Published: Feb 27,2022
Download Gerber file 28
