CAMTASIA_transparent_potentiometer (Time 0_00_02;13).png

Components

	220Ohm Resistor generic resistor	x 2
	Transparent Potentiometer Alpha	x 2
	3mm LED	x 2

Tools, APP Software Used etc.

	KiCAD Kicad
	Adobe Illustrator
	lightburn

Description

Arduino UNO Shield for two Transparent Potentiometers

Learn how to spice up your project with a potentiometer by using a transparent potentiometer that can shine! All this is done by placing a 3mm LED inside the potentiometer since it has a hollow shaft made from transparent plastic. And if you add a transparent knob on top of it, it will look great. In this video, I will also show you how you can create a custom PCB in the form of an Arduino UNO shield.

Screenshots from the video:

Code

Arduino Code

ARDUINO_transparent_potentiometer_sketch.ino

Schematic and Layout

GitHub page

https://github.com/upiir/arduino_transparent_potentiometer

Download Gerbers

Feb 28,2024

1,059 views

Arduino UNO Shield for two Transparent Potentiometers

Arduino UNO Shield for two Transparent Potentiometers, including 3mm LEDs and 220Ohm Resistors. It als includes a front panel made from PCB.

1059

Published: Feb 28,2024

Download Gerber file 6

Other files for Assembly
