Components
|
|
Arduino Nano |
x 1 | |
|
|
Hakko 907 Handle |
x 1 | |
|
|
5 Pin DIN Female Connector |
x 1 | |
|
|
16X2 I2C LCD |
x 1 | |
|
|
LM358 Op-Amp IC |
x 1 | |
|
|
Buck Converter |
x 1 | |
|
|
IRLZ44N MOSFET |
x 1 | |
|
|
470uF 25V Electrolytic Capacitor |
x 1 | |
|
|
470Ω 1/4W Resistor |
x 1 | |
|
|
2.7kΩ 1/4W Resistor |
x 1 | |
|
|
3.3kΩ 1/4W Resistor |
x 1 | |
|
|
10kΩ 1/4W Resistor |
x 1 | |
|
|
10k Potentiometer |
x 1 | |
|
|
24V 3A Power Supply |
x 1 | |
|
|
Buck Converter (MP2303) |
x 1 |
Description
DIY Hakko 907 Digital Soldering Station
Build a cheap and simple DIY Digital Soldering Station, a budget friendly Hakko 907 alternative! Enjoy the variable constant temperature feature and quick warm-up times.
https://www.instructables.com/DIY-Digital-Soldering-Station/
Project Specifications:
- Designed for Hakko 907 handles
- Compatible with similar handles
- Temperature Range: 27°C-525°C
- Warmup Time: 25s - 37s (325°C)
- Recommended Supply: 24V, 3A
- Power: 50W (Average)
Code
https://drive.google.com/drive/folders/1-OA5j5cjvG-Llb6gYXPPmlvDLtvpY8Eu
Schematic and Layout
https://drive.google.com/drive/folders/1-OA5j5cjvG-Llb6gYXPPmlvDLtvpY8Eu
Feb 24,2021
37,800 views
DIY Hakko 907 Digital Soldering Station
2 Layers PCB 48 x 62 mm FR-4, 1.6 mm, 1, HASL with lead, White Solder Mask, Black silkscreen
A DIY budget friendly Hakko 907 alternative for less than $7
37800
126
8
9.64 (37)
Published: Feb 24,2021
BOM(Bill of materials)
PCBWay Donate 10% cost To Author
File Last Updated: 2023/07/07 (GMT+8)
File update record
2023-07-0715:50:08
Parts List (BOM) is updated.
Only PCB
PCB+Assembly
