Description
ESP32-4channelsAC-display-button
Projeto criado para controle do meu aquário. São 4 canais de potência, para controle AC, diversas portas para serem configuradas como desejar, conexão para um display oled, sensor ambiente DHT11, sensor de água ds18b20, comunicação via MQTT e telegram para controle e monitoramento, atualização via OTA, e atualização de data e hora via timeClient
Schematic and Layout
Sep 29,2023
605 views
end-flag
ESP32-4channelsAC-display-button
2 Layers PCB 99.8 x 99.8 mm FR-4, 1.6 mm, 1, HASL with lead, Black Solder Mask, White silkscreen
Criado inicialmente para controle do meu aquário. Possui 4 saídas de potência para controle AC, conexão para display oled e muito mais
