Description
Estlcam Terminal Adapter M
This board is an Estlcam compatible USB CNC controller with screw terminals for easy and reliable connections:
- X/Y/Z Step and Dir outputs with double Y outputs for gantry autosquaring.
- 8 digital inputs for limit switches, probes, buttons and so on.
- 4 analog inputs:
- 2 for resistance measurements (e.g. PT1000 sensors for spindle motor temperature monitoring)
- And two 0-10V inputs (e.g. air pressure or vacuum transmitters)
- 4 digital relay or solenoid valve outputs
- PWM and 0-10V spindle speed outputs
- Estlcam hand wheel pendant connector
Control software ist Estlcam: https://www.estlcam.de/
More information about Estlcam hardware: https://estlcam.de/hardware.php
Schematic and Layout
Schematic_Terminal_M.pdf
Oct 28,2024
811 views
Estlcam Terminal Adapter M
4 Layers PCB 90 x 101 mm FR-4, 1.6 mm, 1, HASL lead free, Black Solder Mask, White silkscreen
Estlcam compatible USB CNC controller with screw terminals
811
1
1
Published: Oct 28,2024
Download Gerber file 24
BOM(Bill of materials)
Centroid file
Other files for Assembly
PCBWay Donate 10% cost To Author
Only PCB
PCB+Assembly
*PCBWay community is a sharing platform. We are not responsible for any design issues and parameter issues (board thickness, surface finish, etc.) you choose.
Under the
Attribution-ShareAlike (CC BY-SA)
License.
