Today we have an awesome project and also a bit dangerous. We are making a homemade full sine inverter of around 500W and check the video till the end if you want to see the results. I’ve made some tests based around the EGS002 driver board and other smaller modules. But this driver could read feedback and control some IGBTs in order to create a steady high voltage sine wave just as our home outlets. As you can see the PCB is quite big and that’s because it has a few different parts and is also made for a lot of power. We will go over each part so you will understand how such an inverter works. I wanted to see if it could be cheaper to make a homemade inverter and also learn something new. So guys, let’s get started and be careful working around high voltage.

Full Tutorial Here: https://electronoobs.com/eng_circuitos_tut83.php
