Led Chaser with help of NE555P Timer chip
This project utilizes the NE555P timer chip to create an LED chaser. The circuit is designed with three red and three yellow LEDs. When power is applied, the red and yellow LEDs illuminate simultaneously. The LEDs are connected in series but opposite coloured are place opposite (input directions), means the output of the chip is alternating.
Schematic and Layout
Schematic.pdf
Dec 17,2024
4 views
Led Chaser with help of NE555P Timer chip
