Components
|
dpdt 5v relay |
x 1 | |
|
555 timer |
x 1 | |
|
spst switch |
x 1 | |
|
1n4001 |
x 2 | |
|
1uf electrolytic |
x 1 | |
|
led |
x 1 | |
|
470r 1/4 w resistor |
x 1 | |
|
10k 1/4 w resistor |
x 2 | |
|
100k 1/4 w resistor |
x 1 |
Description
Relay Bypass for guitar pedal
I wanted a very simple click less bypass to replace a 3pdt in a guitar pedal, this is a dpdt relay bypass with led indicator, using a 555 timer and minimal components, dual sided board makes this very small and is almost the size of a 3pdt using only a few components the cost is similar to a 3pdt but will last much longer and be more reliable and click less. very simple project that could be useful to many other builders and hobbyists. Based on the Dimadash incandenza bypass.
Oct 24,2020
2,819 views
end-flag
Relay Bypass for guitar pedal
very simple dpdt relay bypass with led indicator using a 555 timer and minimal components board and spst switch in place of 3pdt
