Wireless Temperature and Humidity Monitoring System (Base Station)
This is the gerber file for the "Base Station" part of my wireless temperature/humidity monitor system project. I built this project to monitor the temperature and humidity of my room both at my desk, and in my closet where I keep a rack of servers and networking equipment. I wanted to be able to monitor both of these places at one central location, and so I developed this project.
If you're looking for more details on this project and my full detailed tutorial, check out the YouTube video that I made on it on my channel, which you can find at this link.
Wireless Temperature and Humidity Monitoring System (Base Station)
