Description
pippyg 3.62
DigiKey shopping list with revised parts : https://www.digikey.co.uk/en/mylists/list/PZM866RLM3
Build cost is now up to £20.50 per device when building 10. This is because the new SD interface is about £1.50 more expensive, and the non-ceramic caps cost a bit more as well. As always, the 3D print file makes 5 mounts - so if you want to build 10 PCBs, you need 2 (TWO) 3D prints.
Oct 06,2024
116 views
pippyg 3.62
A version of pippyg to address the "SD writing noise" using ferrites and non-ceramic capacitors. Also replaces the SD interface.
