LGK246 : Reversible Split Wireless

Legion Go Keyboard : 2x4x6

This keyboard is mainly designed to fit closely [ not perfectly :( ] to the Lenovo Legion Go.

I recently bought a Legion Go for travel but needed a light, slim and compact wireless keyboard to go with it and here's my output.

The design uses solder bridges to change the keyboard configuration so that one board can be used for the right and left side.

I didn't want to order separate boards for each side and it was a learning opportunity to make a configurable PCB.

Each half will have it's own Seeed XIAO nRF52840 to communicate wirelessly. There's are sets of solder jumpers that need to be connected to configure the pins from the XIAO (below the controller).

This board is designed to use ZMK and I will provide the files for the firmware once I sort it out.
