SIDE3.x wing board
This is never released Side3.x wing board that extends its functionality if used on stock - non U1MB equipped Atari computer.
It adds extended ram support and pbi bios for full ATR file support without the need of U1MB
It also features audio amplifiers as covox and second pokey emulation was planned for SIDE3 project.
Stay tuned for futher JED/FS updates for SIDE3
Schematic and Layout
side-wing.PDF
Aug 18,2024
457 views
end-flag
SIDE3.x wing board
Want to add PBI support and extended RAM without U1MB to your SIDE3.x? here is how
457
3
1
Published: Aug 18,2024
