snes slot cartridge |
x 1 | |
|
|
10k resistor smd 1206 |
x 2 | |
|
|
100nf capacitor smd 1206 |
x 1 | |
|
|
led smd 0805 |
x 1 | |
|
|
PIC12F629Microchip
|
x 1 |
SNES / SUPER FAMICOM Region free unlock pcb
snes/super famicom home zoning adapter
better compatibility than old adapters or needed 2 cartridges from 2 different regions
my adapter cable a supercic has snes instead of the CIC cartridge nintendo
will work with most games, except that have protections in addition to the CIC .
Some titles may have glitchs turned at a frequency other than that where it is designed: 50/ 60hz , or 60/ 50hz.
necessary components:
1 snes slot cartridge
1 pic12f629/675 programmed with the supercic hex
1 resistor 10k 1206 smd
1 capacitor 100nf 1206 smd
optional:
one led smd 0805
1 resistor 10k 1206 smd ( used for led )
the way of insertion is writed on pcb : FRONT , BACK
pcb need to be ordered with a 1.2mm thickness , very important , and ENIG finition minimum.
SNES / SUPER FAMICOM Region free unlock pcb
