Description
Atari Basic ROM multi-adapter
Replaces the 2364 BASIC ROM in Atari XL computers with a 27C1000 to allow you a selection of 16 different 8k ROMs built in.
You must use 16 8k binary images - you can concatenate them in a hex editor or at the command line
The 4 selection pins can be jumpered but a rotary 0-F binary switch works the best
Jul 18,2021
1,657 views
Atari Basic ROM multi-adapter
Replaces the 2364 BASIC ROM in Atari XL computers with a 27C1000 to allow you a selection of 16 different 8k ROMs built in
1657
6
0
Published: Jul 18,2021
PCBWay Donate 10% cost To Author
*PCBWay community is a sharing platform. We are not responsible for any design issues and parameter issues (board thickness, surface finish, etc.) you choose.
Under the
Attribution-NonCommercial (CC BY-NC)
License.
