Capacitor Discharge (Repairing a Switching Power Supply)
Hi, it is a tool with LED indicator to discharge high voltage. Capacitor discharge pen. AC and DC Repair discharge tools 0-400v
It is suitable for discharging capacitors when repairing the hash board or control board to avoid secondary damage caused by short circuit of components or secondary damage caused by current flowing to other components.
