Components

	MT4264 or 4164 or 4864 etc	x 8
	16 PIN DIL SOCKET	x 8
	100N CERAMIC CAPACITOR AXIAL	x 8
	8 PIN IC HEADER	x 4

Description

DRAM Module for Atari C-103579-001 Revised pcb.

This is an alternative, to replace the original two 41464 dram on pcb.

It can use 8x 4164 or 4264 drams, and is ready for 41256 but locked in 64Kx1 page mode.

I want to note that I never built it, so anyone it's doing it is with your own risk.

May 08,2021

1,245 views

DRAM Module for Atari C-103579-001 Revised pcb.

It can use 4164 or 4264 drams, and is ready for 41256 but locked in 64Kx1 page mode.
