Machined DS Cartridge
A machined Nintendo DS cartridge for Original Games
These are machined replacement housings for original Nintendo DS games, i made these after playing around with machined Game Boy cartridges because i thought they would be neat, after posting about them on socials i got a lot of requests and questions for where they could be purchased, so here we are.
Note:
- Please keep in mind that the two pieces need to be glued or epoxied together after assembly
Ordering:
Front:
Select "Ship in assembly for "Parts assembly" (This reduces the risk of shipping damage)
Back:
Select "Ship in assembly for "Parts assembly" (This reduces the risk of shipping damage)
I recommend selecting "Bead blast + Anodized" as the finish for Aluminum
Assembly:
Slot the two pieces together and adhere with a glue or epoxy
CAD-Custom parts and enclosures
DS Cartridge Top
C-H159W82150A_Machined DS Cartridge Top.step
Machined DS Cartridge.pdf
DS Cartridge Bottom
Machined DS Cartridge Bottom.step
Machined DS Cartridge.pdf
Sep 12,2023
4,174 views
end-flag
Machined DS Cartridge
A Machined Nintendo DS cartridge for original games
4174
3
0
Published: Sep 12,2023
PCBWay Donate 10% cost To Author
