Martin Refseth
NORWAY • + Follow
Components
|
|
604050 Battery Cell |
x 1 |
Tools, APP Software Used etc.
|
KiCADKicad
|
Description
New 3DS LipoMod
Batteries for the New 3DS are getting hard to find, this board will allow you to use any 604050 Battery Cell in your console, the 604050 cells generally have a higher capacity than the Original and Aftermarket battery options, which means more play time.
Only compatible with the New 3DS, will not fit any other 3ds.
Order at 1.6mm, preferably with the ENIG finish
Nov 16,2021
5,364 views
New 3DS LipoMod
Batteries for the New 3DS are hard to find, so why not use a generic 604050 cell instead?
5364
12
7
Published: Nov 16,2021
