Phone Line Simulator (POTS Land Line)
Plug an old land line phone or other device into the RJ11 jack, pick up the phone and hear a dial tone.
Take a second duplicate pcb and phone/device, link them with a spare RJ11 cable between them, and dial from one phone to the other.
Hear call progress tones in the phones.
The phone being called will ring until answered.
When a call is answered, the two phones are connected together by the RJ11 cable running between boards and the phones can work as if they are on a live phone service.
Modems can also call each other.
Useful for testing devices, creating a local intercom, and other nostalgic purposes.
Code
ESP32 Sketch
https://github.com/GadgetReboot/Phone_SLIM
Schematic and Layout
Design Files
https://github.com/GadgetReboot/Phone_SLIM
Nov 12,2023
2,922 views
end-flag
Phone Line Simulator (POTS Land Line)
Get land line phones/modems working again in a test setting. Hear call progress tones, make phones ring, and create an intercom/modem link.
2922
12
1
10.00 (1)
Published: Nov 12,2023
Download Gerber file 15
BOM(Bill of materials)
Centroid file
PCBWay Donate 10% cost To Author
Only PCB
PCB+Assembly
*PCBWay community is a sharing platform. We are not responsible for any design issues and parameter issues (board thickness, surface finish, etc.) you choose.
Under the
Attribution-ShareAlike (CC BY-SA)
License.
