Volvo CEM Pin Decoder
This PCB allows the use of a Teensy 4.0 and a pair of Bosch CF160 transceivers to run the wonderful software found at https://github.com/vtl/volvo-cem-cracker. This will allow you to "crack" the CEM pin, allowing you to reconfigure the vehicle. I have confirmed that this works on my P2 V70 R (MY 2007).
Support page for software: https://www.matthewsvolvosite.com/forums/viewtopic.php?f=10&t=85611
Feb 01,2022
8,117 views
end-flag
Volvo CEM Pin Decoder
2 Layers PCB 25.1 x 58.6 mm FR-4, 1.6 mm, 1, HASL with lead, Blue Solder Mask, White silkscreen
8117
7
13
Published: Feb 01,2022
Download Gerber file 129
PCBWay Donate 10% cost To Author
*PCBWay community is a sharing platform. We are not responsible for any design issues and parameter issues (board thickness, surface finish, etc.) you choose.
