ESP32-Radio_PCB_ESP32-Radio
This project is about the realization of an Internet radio based on an ESP32 WiFi module.
For the ESP32 an Internet radio was originally built in 2017 using a VS1053 mp3 decoder. Later on, the software is updated to support I2S output. The latest version also supports SPDIF (Toslink) output.
A 1.8 TFT color display can give some information about the radio station that’s playing. Other types of display are also supported, including NEXTION.
In the simplest configuration, you can build an Internet radio with only 2 components.
ESP32-Radio_PCB_ESP32-Radio
*PCBWay community is a sharing platform. We are not responsible for any design issues and parameter issues (board thickness, surface finish, etc.) you choose.
