µstep_solo Stepper motor control board 3A
This is a simple board to control any stepper motor up to 55V 3A
It's based on LMD18245 half bridge driver
Control is done with a PIC 16F57 MCU programmed in assembler.
Step and Dir signal are needed to control the motor
Full project description is available into my hackaday's project page : https://hackaday.io/project/195056-step-solo-stepper-motor-controler
Everything is Open source / Open Hardware. Source code is available into my github pages : https://github.com/f2knpw/microStep_stepper_control_board
Feb 29,2024
558 views
end-flag
µstep_solo Stepper motor control board 3A
2 Layers PCB 65 x 65 mm FR-4, 1.6 mm, 1, HASL with lead, Black Solder Mask, White silkscreen
simple board to control any stepper motor up to 55V 3A
