Description
Commodore Amiga DB23 External Video Buffer V1
New Version here:
https://www.pcbway.com/project/shareproject/Commodore_Amiga_RGB_VGA_adapter_V2.html
External RGB video buffer for H- and V- sync.
Can be connected to 15KHz video monitors such as BenQ, etc.
U1 M74HCT14B1R (DIP)
C1 0.1uF MLCC X5R (or X7R) 1608/0603
L1 BLM18SP221SN1D chip bead 220 Ohms @ 100 MHz 1608/0603
May 27,2021
1,308 views
Commodore Amiga DB23 External Video Buffer V1
DB23 connector for 15KHz VGA Monitor
1308
6
0
Published: May 27,2021
