Description
ESP32 DIN Rail RS485, Modbus and RGB LED Controller
A PCB layout designed to fit inside a CamdenBoss CNMB-2-2 DIN rail enclosure. Has a 5 to 35V input voltage range, RS485 transceiver and 3 open-collector transistor outputs for driving things like fans, RGB LEDs or other items.
The ESP32 can be programmed with custom code, or flashed with ESPhome to configure Modbus interfaces and LED controllers.
Please see my YouTube video on this design at https://www.youtube.com/sdgelectronics
Schematic and Layout
Dec 19,2023
4,211 views
ESP32 DIN Rail RS485, Modbus and RGB LED Controller
A DIN rail mountable ESP32 device with RS485 Interface and open collector outputs
