IS31FL3731 LED driver |
x 1 | |
|
|
ATSAMD21G18A-A |
x 1 | |
|
|
0.1uF 0603 capacitor |
x 3 | |
|
|
1uF 0603 capacitor |
x 8 | |
|
|
20k 0603 resistor |
x 4 | |
|
|
5K1 0603 resistor |
x 2 | |
|
|
0r 0603 resistor |
x 2 | |
|
|
HRO-TYPE-C-31-M-12 |
x 1 | |
|
|
15pF 0603 capacitor |
x 2 | |
|
|
10k 0603 resistor |
x 1 | |
|
|
MPR121 Capacitive Touch Sensor Controller |
x 1 | |
|
|
4k7 0603 resistor |
x 2 | |
|
|
100k 0603 resistor |
x 2 | |
|
|
75k 0603 resistor |
x 1 | |
|
|
4.7uF 0603 capacitor |
x 2 | |
|
|
2k 0603 resistor |
x 1 | |
|
|
MCP73831 Li-ion Battery Charger |
x 1 | |
|
|
AP2112K-3.3 Linear Voltage Regulator |
x 1 | |
|
|
SWITCH-SPDT-SMD-RIGHT-ANGLE |
x 1 | |
|
|
SW_SPST |
x 1 | |
|
|
Crystal 32.768kHz |
x 1 | |
|
|
Buzzer |
x 1 | |
|
|
Conn_ARM_JTAG_SWD_10 |
x 1 | |
|
|
Li-ion battery |
x 1 | |
|
|
0805 white LED |
x 90 |
Gameboy based christmas tree ornament
A christmas tree ornament made with 90 LED matrix, a buzzer, 8 touch buttons, powered by a rechargeable Li-ion battery. It uses a ATSAMD21 microcontroller, so it's compatible with Arduino and CircuitPython.
It can show animations in the buit-in LED matrix, reproduce Chiptune sounds using the buzzer and interact with a user by touch buttons present in the circuit board. You can use it to play some simple games!
The USB Type-C connector is used to charge the lil-ion battery and to upload firmware to the microcontroller.
Gameboy based christmas tree ornament
