J201 SMD JFET Adapter
Many circuits use J201 JFETs, sadly the TO-92 package are out of production, and many of those that can be found online from China sources are so far out of specification that they do not work. Additionally testing shows wildly different specs regarding tolerance.
Now you can simply use the cheap and readily available SMD SOT-23 package with ease.
Feb 18,2021
1,880 views
end-flag
J201 SMD JFET Adapter
Adapt SMD SOT-23 transistors to through-hole PCB layouts.
