GREGIS Francois

FRANCE • + Follow Edit Project

0

Description

Pellet stove start helper

A simple card to help pellet stove to star with air compressor.

the cart will also clean the burner chamber, remove the water in the air tanker, start and stop automaticly the hot air fan distribution inside the home. the card ave a temperature sensor.

the card is connect to the ignition heater and pelet admision motor to know the stove state.

All parameter can be send and update from RS232 communication.

the card can alow stove to work as usual, or controled by PLC or PC via RS232.

The interface between card and stove is to lie the stone temperature sensor.

The cart works aroun a Arduino Pro mini 328

Download Gerbers

Jan 23,2023

683 views

Pellet stove start helper

A simple card to help pellet stove to star with air compressor

683

0

0

Published: Jan 23,2023
