Components
|
|
M29W320DB70N6STMicroelectronics
|
x 1 | |
|
|
AMS1117-3.3V |
x 1 | |
|
|
10uf smd 0805 capacitor |
x 2 | |
|
|
100 nf smd 0402 capacitor |
x 2 | |
|
|
smd 100 ohms 0603 resistor 101 4x1 |
x 10 |
Description
Sega Megadrive / Genesis flashcard , flashkit md compatible PCB
A Sega Megadrive / Genesis flashcard , flashkit md compatible PCB , completely redesigned . , 4mo capacity / without save function
with holes for Sega genuine shell , and EA shell too
flashable with the krikzz flashkit md programmer , and the china clone of this device too
compatibile with all chips like m29w serie chips ( m29w160xx , m29w320xx , m29w640xx ) in tsop-48
S29gl serie appair to be compatible too
the 160 serie is 2mo only if put it a rom a more than 2mo will not work.
The 640 serie is 8mo , but only 4mo will be accessible .
you need order the pcb with a 1.6mm thickness and enig , or better finiton ( NOT HASL)
necessary parts :
U1 : m29w320xx flashchip or other in same family
U2 : 3.3v regulator
c1 and c2 = 10 uf 0805 capacitor
c3 and c4 : 100 nf 0402 capacitor
R1 to R10 : 100 ohms ''101'' 0603 resistor in 4x1 form factor.
i suggest order them with assembly service , bom and pick and place file are attached
