Example printed circuit boards manufactured by us.

We have the PCB manufacturing capabilities to build simple to complex bare boards.
Please review the example printed circuits below and let us know if you have any
questions or would like a formal quote.

Focus on high-end PCB design, R&D, production, sales, provide customers with high-level, high-speed, high-frequency, high-end,
high-density, high-difficulty HDI PCB design and other types of PCB proofing, customization, board manufacturing and bulk online
order purchase service. The products have covered high-end HDI buried blind hole PCB, 5G communication PCB board, high frequency
and high speed PCB, optical module PCB, semiconductor test, aerospace PCB circuit board and many other fields.

原图
Mouse over to zoom in

4G optical module PCB

Applications
/
Features
/
Material
S1000-2M
Layers
10 Layers
Thickness
1.0±0.1mm
Min Hole Size
Mechanical hole 0.15mm
Min Track/Spacingh
120/85um
Minimum board thickness and hole ratio
/
Surface Finish
Hard gold 2u" + partial Hard gold 50u"
Quote Now
Product Details

4G optical module PCB circuit boards are widely used in optical fiber communications and other fields. The optical module PCB is made of Shengyi S1000-2M material, surface gold-plated and local thick gold-plated production process, the minimum aperture is 0.15mm, and the minimum line width and line spacing is 120/85um. It is an ideal circuit board for optical fiber communication equipment product.

Related Products View more >>
  • 5G optical module PCB

    8 layers, Material: IT968TC, Thickness: 1.0±0.1mm
