Overview: How Does PolyJet 3D Printing Work?

PolyJet 3D Printing Service

PolyJet 3D printing is a powerful and versatile additive manufacturing technology that delivers high precision, smooth surface finishes, and the ability to produce multi-material and multi-color parts in a single build. Ideal for prototypes, functional models, and detailed parts, PolyJet excels in producing complex geometries and fine features with exceptional accuracy.

How Does PolyJet 3D Printing Work?

PolyJet 3D printing works by jetting tiny droplets of photopolymer materials onto a build platform, where they are immediately cured by UV light. This process is repeated layer by layer, allowing for the creation of highly detailed parts with smooth surfaces.

Multiple materials and colors can be combined in a single print, enabling the production of complex, multi-material models. The precision of the droplets and the curing process allows PolyJet to achieve fine details and complex geometries, making it ideal for prototypes, detailed models, and more.

Why Choose PolyJet 3D Printing?

PolyJet technology is the ideal choice when you need parts with smooth surfaces, fine details, and the ability to combine different material properties and colors in one print. Whether you're working on a prototype, a functional model, or a design project, PolyJet offers unmatched versatility and quality.

Benefits of PolyJet 3D Printing

Advantages

High Precision

Achieves layer thickness as fine as 16 microns, ensuring detailed and accurate prints.

Multi-Material & Color Printing

Combines multiple materials and colors in one build, allowing for complex designs.

Smooth Surface Finish

Produces parts with excellent surface quality, often eliminating the need for post-processing.

Wide Material Selection

Offers a broad range of materials, including rigid, flexible, transparent, and high-temperature options.

Applications of PolyJet 3D Printing

Prototyping

Create highly detailed prototypes with accurate color representation and texture.

Medical Models

Produce detailed anatomical models with realistic textures and color differentiation.

Consumer Products

Design functional prototypes or end-use parts with various material properties.

Art & Design

Bring intricate designs to life with high precision and full-color capabilities.

Get an 3D Printing quote

Our PolyJet 3D printing service

Requirement	Specification
Maximum build size	490mm x 390mm x 200mm
Minimum build size	5 x 5 x 5 mm
Minimum wall thickness	1.0 mm
Dimensional accuracy	L<100mm,±0.1mm. L＞100mm, ±0.2mm or 0.06%*L(mm) (Whichever is greater)

The table below depicts the general tolerances for PolyJet services. Stresses during the build, support strategy and other geometry considerations may cause deviation in tolerances and flatness. Improved tolerances may be possible with a manual quote review, after successful completion of a prototype build, and must be approved on a case-by-case basis.

Surface Finish and Post-Processing Options

item	note
STANDARD	Bead blast to remove all powder, which leaves a consistent overall texture.
CUSTOM	Secondary options include a primer or dye color that can be applied as well as taps and inserts.

Our CUSTOM surface finishes

Here is a list of standard surface finishes. For custom surface finishes such as electroplating or polishing, please contact 3dcnc@pcbway.com.

Spray painting

Get painted according to the color pattern provided by the customer (Including matte paint, high-gloss paint, electroplating-imitation paint, varnish, leather paint,etc).

Polished

The surface texture is polished in a variety of ways to meet the actual needs of customers. The transparent parts can be polished accordingly to improve transparency and light transmittance.

Electroplating

Provide electroplating services, improve the overall strength of the parts, provide metal-like surface texture, and make it have certain metal characteristics.

Inlay nut

At the specific bottom hole position that needs to be processed, the internal thread is processed.

Glazing assembly

The surface of the part is glazed to better imitate the appearance of handicrafts. Have mature assembly experience to ensure the overall display of the product.

Reinforced coating

The unique outer coating processing ability improves the strength of the product structure, reduces external wear, and can better avoid damage caused by normal storage and use.

Testing Service

A variety of measuring equipment provides reasonable measure services according to the actual needs of customers.

Multi-industry applications of 3D Printing services

We offer excellent 3D printing product support across various industries including automotive, healthcare, cultural creativity, and industrial sectors.
