Example printed circuit boards manufactured by us.

We have the PCB manufacturing capabilities to build simple to complex bare boards.
Please review the example printed circuits below and let us know if you have any
questions or would like a formal quote.

Focus on high-end PCB design, R&D, production, sales, provide customers with high-level, high-speed, high-frequency, high-end,
high-density, high-difficulty HDI PCB design and other types of PCB proofing, customization, board manufacturing and bulk online
order purchase service. The products have covered high-end HDI buried blind hole PCB, 5G communication PCB board, high frequency
and high speed PCB, optical module PCB, semiconductor test, aerospace PCB circuit board and many other fields.

原图
Mouse over to zoom in

High-density aerospace PCB

Applications
Aeronautics and astronautics
Features
/
Material
RO4350B+TU-768
Layers
24 Layers
Thickness
3.2±0.32mm
Min Hole Size
0.25mm
Min Track/Spacingh
75/75um
Minimum board thickness and hole ratio
12.8:1
Surface Finish
Immersion gold(ENIG) 0.05um
Quote Now
Product Details

The 24-layer high-density aerospace PCB is referred to as the 24-layer aerospace circuit board. The circuit board is widely used in the aerospace field.


Related Products View more >>
  • Microwave radio frequency PCB

    4 layers, Thickness: 1.6mm, Finished Copper: 1 oz

  • High frequency PCB

    2 layers, Thickness: 1.65mm, Finished Copper: 1 oz

  • Multi-layer blind hole high frequency PCB

    6 layers, Thickness: 1.6mm, Finished Copper: 1 oz

  • 6-layer high frequency PCB

    6 layers, Thickness: 1.6mm, Finished Copper: 1 oz

  • 4-layer mixed high-frequency PCB

    4 layers, Thickness: 0.8mm, Finished Copper: 1 oz
