Description
ZX Spectrum FlashCart adapter
Very simple adapter for external flash cartridges (i.e. games or diagnostic ROMs).
By using a jumper you can use it with almost all types of ZX Spectrum computers :)
Diodes - 1N4148 / 0805 / SMD
Cartridge slot - Industrial Card Edge Slot Socket Connector 15x2P 30P 2.54mm 0.1"
Edge Connector - Industrial Card Edge Slot Socket Connector 28x2P 56P 2.54mm 0.1"
