Description
DIY DIGITAL CLOCK
THIS IS A SIMPLE DIGITAL CLOCK THAT WORKS WITH A 9V BATTERY AND CAN BE SET JUST THREE BUTTONS.
IF U LIKE THIS PROJECT , PLS LIKE :)
U WILL NEED: seven segment display(4), 4 pin push button switch (3), 4.00MHz crystal , 220N capacitor, PIC16F84A ic , 22PF ceramic capacitor (2), LM7805 voltage regulator , 2.2K resistor (8), 10k resistor (4), 820E resistor .
PLS LIKE MY PROJECT :)
Dec 01,2018
6,392 views
end-flag
DIY DIGITAL CLOCK
2 Layers PCB 57 x 54 mm FR-4, 1.6 mm, 1, HASL with lead, Black Solder Mask, White silkscreen
6392
8
2
5.44 (4)
Published: Dec 01,2018
Download Gerber file 191
