20-layer server backplane PCB

PCB Products / High-level PCB / 20-layer server backplane PCB

Mouse over to zoom in

Applications

Server field

Features

High speed material + back drill

Material

TU-872

Layers

20 layers

Thickness

5.0±0.5mm

Min Hole Size

Min Track/Spacingh

75/75um

Minimum board thickness and hole ratio

12:1

Surface Finish

Quote Now

Product Details

The 20-layer server high-level backplane PCB is made of Tai Yao TU872SLK material and surface immersion gold technology. The PCB circuit board is widely used in data center server PCB backplanes.
