Raspberry Pi Pico Rocket Flight Computer

A raspberry Pi powered Rocket flight data acquisition and monitoring system. 3.7V LiPo Battery Power Supply

Features:

• Pi Pico Core processor
• 3.7V LiPo Powered
• On Board battery charging and management system
• GPS NEO6m Module
• LoRa SX1278 Ra-02 Ai thinker
• Barometer BMP280
• Accelerometer and Gyro MPU6050
• SD Card module for data logging
• GPIO header for external peripherals
• Easy to solder Modules compatibility
• Charging Indicator LED
• Freedom Of use (You can skip unwanted Features. Simply not to add that module to the system)

Dimensions:

• 90mm x 90mm
• 2mm 4x screw mounts

Technical Info:

• Size:90mm x 90mm
• Signal Layers:2
• None Signal Layers:10
• Components:22
• Pads:135
•  Surface Pads:81
•  Plated Through-hole Pads:54
•  None Plated Through-hole Pads:0
• Holes:9
• Vias:10
• Nets:41/41
• Length of Tracks:1777.21mm
• Copper Areas:2

Open Source Design:

All the documentation and source files are available of The GitHub
