  • Thanks to iNimbleSloth for this awesome video; https://youtu.be/Z7LgxNULqmk

    Reply
  • Thank you for the project sharing. Works great with the RPI ZERO.

    (DIY) C64iSTANBUL 2024-10-10 16:35:02Reply

    You're welcome.

    Reply
  • Having issue with getting the display to display anything. I get "FASTLOAD" on my C64 so the Epyx Fastload is good. I tried multiple SD cards. My Pi Zero is good as it working with my PiDrive Zero with no problems. I can't get anything out of the display. Tried multiple Kernels. I download a link that was a copy of a working SD directory from a link and still can't get it to work.

    (DIY) C64iSTANBUL 2023-08-22 16:20:07Reply

    Hello, Did you solder the jumpers on the back of the PCB according to the display model?

    Hi I have the same issue, I solder the jumpers on back My display has GND, VDD, SCK, SDA so I solder both marked as GND. Hope you can help. Thank you!

    (DIY) C64iSTANBUL 2024-06-01 23:47:55Reply

    Hello David Alejandro Gonzalez Priego, Please send me an email to c64istanbul@gmail.com with both front and back photos of your Soldered PCB.

    Sure I'll send the photos of the back of the PCB to do a double check, but I think I discover the issue. I Ordered a the PI Zero, but I realized that I have received the PI Zero W, that's might be the issue

    (DIY) C64iSTANBUL 2024-06-04 05:14:55Reply

    There are ready SD card files for pizero and pi zero2 on this page, maybe it can help you. http://www.load64.com/epyx/

    (DIY) C64iSTANBUL 2024-06-14 15:49:02Reply

    Hello, did you solve the problem?

    Reply
  • Hi, would you choose edge connector for this when ordering the PCB, the same as your other designs? So 45 degree bevel?

    (DIY) C64iSTANBUL 2024-05-24 15:54:24Reply

    I modified the GERBER files. Yes, from now on you can choose the edge connector for it when ordering the PCB, so 45 degree bevel. Thank you for asking.

    hellraiseruk 2024-05-24 16:29:39Reply

    Thank you, only problem is I selected edge connector and placed the order just before you changed the Gerber, will this be a problem? Knew I should have waited :)

    (DIY) C64iSTANBUL 2024-05-24 19:07:49Reply

    No, it won't be a problem if you ordered it with the previous Gerbers, I just extended the PCB length by 0.3mm from the edge connector section. Thank you.

    hellraiseruk 2024-05-27 15:19:00Reply

    Hi, No worries - I managed to cancel and reorder in time, so just waiting for the boards to be made now. Thanks again!

    Reply
  • Can this be daisy chained to a real 1541 disc drive? If so can it be connected directly to the back of the real drive, other than possible configuration, is anything else required?

    (DIY) C64iSTANBUL 2024-05-15 13:53:07Reply

    No, this cannot be daisy chained to a real 1541 disk drive. Malfunction may occur due to voltage differences. Thank you for asking.

    Reply
  • Hello, can you show me a picture, on how to assemble the 6 Pin DIN Connector by using the 74LS07, please. Thank you.

    (DIY) C64iSTANBUL 2024-05-09 23:36:10Reply

    Hello, I am sorry, I don't understand your question.

    Engineer 2024-05-09 23:53:29Reply

    Is there a picture or pictures which shows how to make the Cable with the 6 PIN DIN Connector which goes into the IEC of the C64?

    (DIY) C64iSTANBUL 2024-05-09 23:59:10Reply

    https://pcbwayfile.s3-us-west-2.amazonaws.com/project/21/02/08/0742130953540.png

    (DIY) C64iSTANBUL 2024-05-10 00:00:34Reply

    1-2-3-4-5-6 numbers on the PCB should match the connectors numbers.

    Engineer 2024-05-10 00:07:27Reply

    Ah, ok. That was my question. Sorry for the misunderstanding. I will solder the 1 on the PCB to 1 in the Connector and so on. I hope I understood it now. :-)

    Reply
  • What is the pin spacing for a header to connect the DIN cable to the board? 1.25 or 2.54mm?

    (DIY) C64iSTANBUL 2024-05-03 00:20:18Reply

    2.54mm

    Reply
  • i have a pi zero 2 w is this not compatible with it? i can't get it to work

    (DIY) C64iSTANBUL 2022-03-08 05:27:38Reply

    Hi mightywiz, I don't have pi zero 2w, I haven't tried it with pi zero 2w. Thanks for asking.

    mightywiz 2022-03-08 10:11:34Reply

    when i create the SD card, the following the instructions nothing happens. the led doesn't flash, telling me it doesnt recognize the image i created. but it will boot the card before any of the 1541 changes are made.

    mightywiz 2022-03-09 02:10:01Reply

    here is the fix for the rasberry Pi zero 2w: Raspberry Pi firmware is updated after the Pi Zero 2 release. https://github.com/raspberrypi...master.zip You need to use the updated bootcode.bin, fixup.dat and start.elf (found in firmware-master\boot) It also needs CPU overclocking.Here is the config.txt kernel_address=0x1f00000 force_turbo=1 arm_freq=1300 over_voltage=4

    mightywiz 2022-03-09 02:10:51Reply

    the fix was not created by me but found on the lemon64.com website

    mightywiz 2022-03-09 02:11:35Reply

    https://www.lemon64.com/forum/viewtopic.php?t=67978&start=2415

    (DIY) C64iSTANBUL 2022-03-13 21:38:41Reply

    Thank you mightywiz.

    mightywiz 2022-03-22 05:30:32Reply

    the fix was hard to follow so what i did was follow in instructions for the rpi b+ board to setup the sd card. then at that point I modified the config.txt to what was stated on the lemon64 page. then updated the options to match suggetsted settings. last I copied the bootcode.bin, fixup.dat and start.elf from this firmware at this link https://github.com/raspberrypi/firmware/archive/refs/heads/master.zip then it ran. I tried in different orders but this was the only way to make it work. and it's been running flawlessly on my pi zero 2w with no issues.

    mightywiz 2022-03-22 05:32:51Reply

    if anyone needs some help getting it to work shoot me a message at mightywiz@hotmail.com and i'll give you a working folder you can drop to the sd card if you can't get your PI Zero 2w to work.

    (DIY) C64iSTANBUL 2022-03-31 16:16:21Reply

    Thank you mightywiz.

    Federico Salis 2023-02-17 19:22:19Reply

    hi, I should also use the rasp pi zero 2w but the link is no longer reachable

    hellraiseruk 2024-01-19 19:03:35Reply

    Not sure why the Zero 2W needs an overclock, but didnt work properly till I overclocked it to 1150 with over_voltage of 4 and is now fine.

    Reply
  • Another great project. Thanks C64iSTANBUL! I have one question though. Epyx FastLoad is great, but it doesn't work with C128 (boots into C64 mode). Would it be possible to adapt this board to work with WarpSpeed, that will work with both C64 and C128? https://github.com/SukkoPera/OpenC64WarpSpeed

    (DIY) C64iSTANBUL 2021-04-01 03:54:42Reply

    Thank you Martin Damm Laupstad. I am sorry that I can not work on a C128, Because I do not have a C128. C128 is very rare in Turkey. Thank you for asking.

    Laupert 2021-04-01 16:07:26Reply

    Someone should send you one as a thank you for all your great designs :)

    (DIY) C64iSTANBUL 2021-04-02 02:41:26Reply

    Thank you :)

    babaroga 2021-04-05 21:42:33Reply

    This is a great design that I like. Where can I get Gerber files? I would like to make a few mods, like adding Rotary Encoder and also if using 27c256 or 27c512, to use the remaining space of those EPROMs with dip switches for other programs. Many Thanks.

    (DIY) C64iSTANBUL 2021-05-25 23:32:59Reply

    Thank you babaroga, I am sorry I do not share downloadable Gerber files.

    Engineer 2021-11-29 04:14:15Reply

    Please share the Gerber files (not the KICAD or Eagle board/schematic files) to a github site, so that hobbyists can have a choice besides PCBWay, which is WAY too expensive just to make 5 pieces of this board. Total cost is $29 USD for 5 pieces. Come on! Really appreciate your work. You already have put in PCBWay, why not github? Thank you!

    (DIY) C64iSTANBUL 2021-11-29 04:34:54Reply

    Hello, sorry I don't share any Gerber files. 10 pieces PCB = $5 + shipping, total about $17-18 via China Post. Less than 2 USD for a PCB is a reasonable amount. I have tried many PCB companies and PCBWay is a really good company. Thank you.

    Engineer 2021-11-29 22:51:12Reply

    Hi, I respect your decision, since you design the board. I can get 10 pcs (100mmx100mm or less two sided boards) for $5 at cheaper shipping cost at other PCB manufacturer actually. I feel that PCBWay is way too expensive. It seems that you have a connection with PCBWay. Again, I can understand completely, since it's your design, and hobbyists have no choice but to use PCBWay.

    (DIY) C64iSTANBUL 2021-11-30 00:15:40Reply

    When people order 10 PCBs and pay $5+ shipping, PCBWay pays 50 cents to my account balance (10% of the PCB price excluding shipping) so I can draw and order new PCB prototypes. Thank you for your understanding.

    Philippe CYUL 2023-05-01 00:27:06Reply

    Hi, could you please share the outline of the PCB as an SVG? I am trying to design a case that would fit this project. Thank you.

    (DIY) C64iSTANBUL 2023-05-01 01:11:05Reply

    https://archive.org/download/pi1541FL_outline/pi1541FL_outline.zip

    Philippe CYUL 2023-05-01 08:56:50Reply

    Thanks a lot!

    hellraiseruk 2024-01-19 19:02:33Reply

    Hi, is Warpspeed just a cartridge? If so, try flashing that ROM instead of the Epyx Fastload and see what it does...

    Reply
  • Hi, built one of these and it seems to work well, but the test with Ghosts and Goblins gives me a scrambled screen. I assumed this meant it was down to the 7407 I was using, but as this is based on option 1 isn't that just used for the Fastload part of the board and not the actual Pi1541? Has anyone else got the same issue with Ghosts and Goblins?

    (DIY) C64iSTANBUL 2024-01-19 17:00:42Reply

    Hello hellraiseruk, The problem is not related to the 7407. Can you please try normal loading with the fastload cartridge turned off? Maybe fastload and the game may not be compatible with each other. Thank you.

    hellraiseruk 2024-01-19 19:00:59Reply

    Hi, thanks for that - I've upped the overclock slightly to 1150Mhz and set over_voltage to 4, this seems to have resolved the issue as G&G now loads fine, and also the Pi is slightly cooler. So far so good!

    Reply
  • if you are interested I have adapted a case for this project, obviously free https://www.thingiverse.com/thing:6312691

    (DIY) C64iSTANBUL 2023-11-14 01:22:14Reply

    Thank you Federico Salis. Ths is a nice case.

    Federico Salis 2023-11-14 02:40:50Reply
    Federico Salis 2023-11-14 03:36:15Reply

    or https://www.printables.com/model/646471-pi1541-epyx-fast-load-cartridge-case

    Reply
  • Thanks for this project !

    Reply
  • Has anyone figured out how to get the LED on the PCB to work? Am I missing something in the settings/options?

    Philippe CYUL 2023-03-06 00:36:03Reply

    See here: https://github.com/pi1541/Pi1541/issues/206#issuecomment-1162708867

    Federico Salis 2023-11-14 00:22:08Reply

    Use my 1.23 release with led fix https://github.com/FSMaker77/Pi1541

    Reply
  • Thanks to AnotherMaker for this great video; https://youtu.be/AJlVrFAR1rc

    Reply
  • I would like to order this assembled from pcbway, but can't tell from the cart if all the parts are included. Is there a file to upload for assembly?

    (DIY) C64iSTANBUL 2023-09-11 22:54:35Reply

    There is no file to upload for assembly, there is a list of components in the descript_ions, and the mounting locations are marked on the PCBs. The PCBs I draw and share are for DIY. I am sharing them so that amateurs interested in elecronics hobby can make them themselves. Thank you for asking.

    Reply
  • I have a couple question for someone who has build this Pi1541 + EPYX FAST LOAD CARTRIDGE for COMMODORE 64. Do you use the Raspberry Pi Zero external power plug off it's board? Even when you are plugged into the cartridge expansion port? I have build one and when I plug it into the C64 cartridge expansion port and the serial port all I get the word Fast load displayed on the C64 screen. No red led light or anything on the little screen.

    (DIY) C64iSTANBUL 2021-04-20 09:02:13Reply

    Hello Douglas Peterson. Question: Do you use the Raspberry Pi Zero external power plug off it's board? Even when you are plugged into the cartridge expansion port? Answer: No, do not use Raspberry Pi Zero external power plug, the circuit gets all the power it needs from the commodore-64, never connect external power when you are plugged into the cartridge expansion port. Did you set power solders for the OLED screen, at back of the PCB? Please check if you prepared the microSD card correctly with right files?

    Douglas Peterson 2021-04-20 10:47:13Reply

    My OLED screen is VGA-GND-SCL-SDA. There is 2 sets of VCC. Do you jumper both sets?

    (DIY) C64iSTANBUL 2021-04-21 02:53:15Reply

    Yes, both two VCC jumpers for VCC-GND-SCL-SDA pin order displays

    Federico Salis 2023-03-28 19:12:01Reply

    I have GND VDD SCK SDA ... I made a bridge between the GNDs, correct? but I don't see anything on the display

    Federico Salis 2023-04-05 00:46:05Reply

    ok solved... it was problem with kernel 1.24... 1.23 works

    Reply
  • Do you know if your design will fit any of these two cases? They look similar, but not sure if they are the same: https://www.thingiverse.com/thing:4541283 https://www.thingiverse.com/thing:4573111

    (DIY) C64iSTANBUL 2021-04-15 20:29:34Reply

    Hello Martin Damm Laupstad, blockmind's case is not suitable (7mm short). I do not have any information about MrLurch's case. You would better to ask MrLurch himself. Thank you.

    Tad Mcdole 2021-07-19 05:01:01Reply

    I have modified Blockminds case to fit the PCBWAY version of the board. https://www.thingiverse.com/thing:4895556

    (DIY) C64iSTANBUL 2021-08-12 23:23:05Reply

    Thank you Tad Mcdole.

    Steeve Rioux 2021-10-10 20:05:15Reply

    Thanks a lot for sharing your design :)

    Federico Salis 2023-03-07 16:27:09Reply

    hi, does it work? I don't see anyone who printed it

    Reply
  • Does anyone made split IEC lines work ? when enable splitIECLines = 1 i have to enable invertIECInputs = 1 otherwise LCD only flash and pi does not seems to work i assume this invertIECOutputs = 1 is set for 7407 thanks

    Praetorian_Joe 2022-08-08 21:50:59Reply

    i see now it is only A schematics ...

    Reply
  • Hi, Great project. I have built one of these and it works brilliantly. I wonder if you had considered doing a board based on the Option B schematic? Mick

    (DIY) C64iSTANBUL 2022-07-04 16:05:46Reply

    Hi Mick. Thank you very much. I'll think about the Option B schematic.

    Reply
  • Many thanks to Cristiano Goncalves. https://tech-peanuts.com/2022/01/17/lets-build-retro-edition-a-cartridge-for-the-c64-combining-the-pi1541-with-the-epyx-fast-loader/

    Reply
